DSE 330

DSE Separation plant


The DSE 330 is a compact separation system specially designed for Dewatering of sludge and for the separation of mineral Solids from suspensions when drilling deep or similar Applications with high levels of silt was designed.

It is an optimal combination of well-preserved separation components Processing plant operating as a self-contained system works. In each separation stage there are as many solids as possible deposited. The modular arrangement guarantees you continuous and fast process and reduces downtime to one Minimum. The innovative screening technology in connection with hydro cyclones forms a closed recycling concept that also includes the disposal of the critical fines up to 20 μm grain size achieved and uniform rinsing properties guaranteed.

The DSE 330 also uses one (1) linear vibratory screening machine Pre-separation of coarse solids such as gravel and clay lumps, one (1) linear vibration screening machine for the separation of coarse solids such as gravel, pebbles and coarse to medium-grain sand, four (4) hydro Vacuum cyclones with a size of 12 ", one (1) linear vibratory screening machine for the separation and drainage of the underflow of the Hydrocyclones, which contain solids such as fine sand and silt, one (1) 20-foot process tank with integrated spraying and one (1) integrated WARMAN high-performance feed pump as well as one (1) central Switching unit together with accessories.

An assembly area for expansion the system is equipped with one (1) KSB Etanorm TBM centrifuge feed pump already provided for a further separation process by means of Connect centrifuges.

Adjustable discharge chutes, a foldable work platform and pluggable ones Railing parts ensure a safe and optimal working environment Access to the system parts and make the system immediately

ready for operation. This reduces the construction time to a minimum. The loading the vibrating screening machines and the cyclones are carried out in a space-saving manner a firmly integrated piping and piping system.

The wiring is permanently installed on the tank so that it is dismantled of the 20-foot container frame, there are no hanging cables. To the Transport, the entire system can be divided into two parts: a 20- Fus tank and a 20-foot container frame in which all equipment can be attached.

All components such as screening machines, cyclones and hoppers are in one 20 foot container frame installed and all electrical Cabling can be plugged in individually for each part of the system.

The vibratory screening machines can be supplied with a wide range of various clamping and frame sieves can be fitted, which are in Mesh sizes from 4 mm to 45 μm are available. The advantage of this design is that the individual components, so both the process tank and the container frame including screening machines can be combined with existing system components. Existing Plant parts with individual components expanded or exchanged become.

Tank (including pump and folded working platform)

Length 6058 mm
Width 2438 mm
Width 4600 mm  (unfolded )
Height 2438 mm

20 ’frame with screening machines and cyclone unit

Length 6058 mm
Width 2438 mm
Height  2895 mm
Height  6300 mm (assembled, working position)
Total weight (approx.)  18500 kg

Technical data:

Capacity (max.) 3 330 m3 / h
Total output 96 kW  (without winter package)

1. about; assembled on site
2. deviations possible
3. The performance of the DSE 330 depends on the sludge properties, solids content, grain sizes, Sieve         selection as well as the operating conditions, and can therefore, if necessary, from the information

Vibration screening machine first cut DSE 400CS / PS

Number installed  2 pc.
Number of decks (each)  1 pc.
adjustable ceiling inclination  0° bis +30°
Total screen area 2.4 m²
Panel sieves per sieve machine 10 pc.

Vibrating screening machine Zyklone DSE 35PSM

Number installed  1 pc.
Number of decks (each)  1 pc..
adjustable ceiling inclination  5° bis +3°
Gesamtsiebfläche 3.2 m²
Total screen area 3.2 m2 Panel sieves per sieve machine  4 pc

Vibration motors OLI 5500/15

installed power (each ) 6 x 3.6 kW
Power supply  400V / 50Hz / 3phase

Hydro-vacuum cyclones 12 ”DSE 12C

Number installed  4 pc.
Cyclone size  305 mm (12”)
Separation cut  25 μm4

Centrifugal pump feeding cyclones Warman DMU 200/200

Number installed  1 pc.
installed power  75 kW
Power supply  400V / 50Hz / 3phase


4 (at 1.1 bar + 4 x 78 m³ / h) based on - viscosity: 80 kg / m * s; Density suspension: 1.47 kg / l; Density dry content: 2.48 t / m³
